Clock Domain Crossing
The primary goal in safely implementing any IC or FPGA project is to achieve a synchronous design. This implies that the relationship of all clocks and asynchronous resets to each other is defined in the synthesis constraints. Incorrect handling of c...
The primary goal in safely implementing any IC or FPGA project is to achieve a synchronous design. This implies that the relationship of all clocks and asynchronous resets to each other is defined in the synthesis constraints. Incorrect handling of clock-domain crossing (CDC) is probably the primary cause of sporadic errors, which are impossible to catch in a digital simulation and can cause a system to inexplicably fail in the field.
This webinar discusses situations in which CDC problems can occur and more importantly presents solutions for the most frequent scenarios.
Topics include:
-
What causes metastability
-
How to correctly implement CDC logic for simple signals, complex data and counters
-
How to use Synopsys Design Constraints (SDC) to ensure that static timing analysis (STA) produces reliable results in the context of multi-clock designs
The webinar will also feature a working example from Microchip® using PolarFire® FPGAs and SoCs and the Libero® SoC Design Suite.
Wednesday, November 06, 2024
Time: 10-11am (GMT) 11-12pm (CET) 3.30-4.30pm (IST)
Americas
Wednesday, November 06, 2024
Time: 10-11am (PST) 11-12pm (MST) 12-1pm (CST) 1-2pm (EST)
